POPU Valve：Stainless Steel Lift Check Valve
Lift check valve is a regular valve. It is installed vertically, and its disc is positioned along the center to move up and down.
| Name | 1-Body | 2-Seat | 3-Disc | 4-Gasket |
| Material | CF8 | CF8 | 304 | PTFE |
| Size | PN16 | |
| DN | NPT | L |
| 15 | 1/2'' | 59 |
| 20 | 3/4'' | 67 |
| 25 | 1'' | 78 |
| 32 | 1 1/4'' | 90 |
| 40 | 1 1/2'' | 99 |
| 50 | 2'' | 117 |
| 65 | 2 1/2'' | 148 |
| 80 | 3'' | 172 |
1. The main material meets the requirements of national regulations
2. All valve accessories are processed by CNC machine tools to ensure product accuracy;
3. After pressure test, the valve will be cleaned again, the anti-rust oil is sprayed.It is easier for long term storage. The cleanliness of the inner cavity meets the requirements of JB/T7748.
4. Each valve must be tested pressure as per national standards when leaving the factory, unqualified products will not be delivered.
5. Each valve adopts special thread blocking protection to prevent thread damage during transportation;
6. G thread, NPT thread, BSP and other customized threads can be provided according to customer needs.
